Brass Hot & Cold Water Mixers
View more Images

BRASS HOT & COLD WATER MIXING UNIT – 3600M-B SERIES

Features:
  • Incorporated Y-style body with check valves and ball joint unions for superior flexibility during installation.
  • Inlet center lines which have the same dimensions as most of our competitors.
  • Includes mounting plate, hose rack, and optional temperature gauge
Principal Parts, Material & Ratings
Inlet / Outlet Diameter: 3/4″ NPT Mixer Body: Brass Globe Style Valves: Brass / Stainless Steel Check Valves: Brass Temperature Gauge: (optional) Stainless Steel Maximum Pressure: 150 PSI Maximum Temperature: 200° F (93° C) Weight: 20 Lbs.

SuperKlean’s hot & cold water mixing unit was specifically designed for thoroughly blending hot and cold water instantly by mixing supplied hot water with cold water to achieve required temperature output. The unit uses “Y” style body mechanics with lift check valves and ball joint unions for superior flexibility during installation. SuperKlean’s inlet center lines have the same dimensions as most of our competitors’ units. Our units come with a mounting plate for easy behind the unit cleanup, hose rack for easy user access to the hose, and an optional temperature gauge for accurate temperature readings at outlet.

Click Here For Technical Drawing

Click Here For 3600M-B Part List

PLEASE CLICK HERE TO VIEW THE SUPERKLEAN 3600BM-B HOT & COLD WATER MIXING UNIT SPECIFICATION SHEET

PLEASE CLICK HERE TO VIEW THE SUPERKLEAN 3600M-B HOT & COLD WATER MIXING UNIT SPECIFICATION SHEET
